Author Topic: The World Is One  (Read 18005 times)

Bjørn Rørslett

  • Fierce Bear of the North
  • Administrator
  • ***
  • Posts: 8252
  • Oslo, Norway
The World Is One
« on: June 18, 2015, 15:58:40 »
[ Posted 19 April 2015 Edited and reposted by agreement ]

Everyone by now knows I'm infatuated with the Nikon Df camera  and that it has been my daily work horse even before it was launched in November, 2013. A lot has been posted on the 'net on this topic by myself and other, sadly, some contributions have fallen prey to censorship for strange reasons. Perhaps the Df is pure dynamite as well?

Now, I happen to believe in the concurrency principle for cameras as well as for human relationships. Thus for all the time with the Df cameras I also brought with me various models from the 1 Nikon range. Initially I purchased a nice 1V1 at rock-bottom price when it went on fire sales, and added more lenses to it over the years. I also got adapters (FT1 and third-party) to use Nikkors  and more exotic lenses on the 1 series cameras. A year ago I also got the AW1, a roughened model capable of surviving over and under water (provided you use with the dedicated AW Nikkors of course).

The 1 Series models and their CX mount lenses are not made with the professional photographer in mind. The features are simplified and aspects deemed essential for 'pro' usage are left out. For example, there is no way you can focus manually* (except the 32 mm f/1.2 which offers focus-by-wire). To balance the picture as it were, you have a neat inconspicuous camera and fast-responding AF when the dedicated CX lenses are used: A perfect combination for a lady's purse or a spacious pocket.

* (added: these lenses lack a focusing collar and any MF has to be performed through the menus by pushing buttons. In my view, this is just a gimmick and highly impractical. The 32/1.2 does have a collar to allow focus-by-wire, but focusing feel isn't great and neither is accuracy))

The small CX format confers drawbacks and advantages. To deal with the problems first; image clarity is easily impacted by graininess if you push the ISO settings too far up, dynamic range is less convincing than with current DX or FX models, and the user interface can take time - if at all - to understand. These issues are to seen against having a small camera easy to bring with you at all times, very fast AF operation, decent video capability if you're not in need of anything more sophisticated than good HD quality, and the versatility of experimenting with highly unusual or exotic lenses. Since focal lengths of the native lenses need to be fairly short, you can get a lot of depth of field just by stopping a little down. The overall image quality suffices to make files that are acceptable to my stock library. Thus they really aren't that bad. These cameras are not just toys. Even GPS is supported, either built-in or as an accessory.

The perceived lack of features should not prevent even seasoned photographers from dabbling with 1 Series models. Perhaps the limited feature set enforces a stream of mindfulness to unleash your creative potential by making you better aware of yourself as the decisive factor for creating photographs. I'm not ashamed of admitting that I like the CX concept much more now after initially being set pretty firm against it.

My current 1 Series models are as follows;

  • Nikon 1 V1: The model that set the CX format going. Very elegantly shaped and with its elegance comes an impractical user interface that really is an acquired taste to swallow. It handles better with a custom-built grip attached. Erik [Lund] aka Dr. Lens to the rescue again. The 1 V1 sports a 10 MPix sensor and should be run at quite low ISO settings if you want a clean image. ISO 400 is usually okay, though. The EVF finder is far too bright and normally I try to use the rear panel instead. There is an accessory shoe in a proprietary layout that allows you to mount various accessories. I use it for plugging in a small GPS receiver, or a cute small LED-based flash device.


  • Nikon AW1: Announced to be waterproof down to 15 m or so, the AW1 packs a 14 MPix sensor in a casing bigger than the 1 V1. It is also heavier so easier to hold. With either of the dedicated AW Nikkor lenses it tolerates being knocked about and should survive a drop  from 2 m height  (if you let it fall on not too hard ground).  Unlike the 1V1, there is no EVF to nag me. The camera has a well-functioning GPS built in, but due to the nature of things reliable geocoordinates are only attained for land use of the AW1. ISO performance is better than the 1 V1, but miles away from what my Nikon Df would provide.

    The AW Nikkors utilise a large skirt to their rear that slides over and sits firmly against an O-ring surrounding the lens mount. Provided you clean off dirt and grime from the O-ring and keep it lubricated, the watertight connection is simplicity itself and only reveals its double function by the lens being very stiff to remove or attach. A collar, supplied with the camera, protects the O-ring when you want to mount ordinary CX lenses or adapters. Just remember the camera then no longer is water tight.

    I have added a silicone skin - in orange - to the AW1 and its 11-27.5 lens in order to make the package appear similar to my beloved Nikonos of the past, plus this skin makes the outfit tolerate even more abuse.

    The user interface of the AW1 is simplified to allow the camera to be operated under water with gloved hands. This means some functions are only reached by going through menus, so set up the camera to your preferred usage pattern. Just like the 1 V1 and other 1 Series models, it does HD video with excellent quality and of course you can capture your footage of the submersed world too.


I own the following CX lenses;

  • 6.7-13 mm f/3.5-5.6
  • 10 mm f/2.8
  • 10 mm f/2.8 AW (sharper than the non-AW, by the way)
  • 11-27.5 mm f/3.5-5.6 AW (underwater version of the 10-30 kit lens)
  • 18.5 mm f/1.8 (provides a 'normal' angle of view)
  • 10-100 mm f/4-5.6


All are good performers, but my nod goes to the AW versions. The fast 18.5 is also top-notch, and the 10-100 I recently got second-hand for a song is no slouch either. I also used the kit 10-30 mm f/3.5-5.6 zoom and you do get decent quality for a very low price with that lens. Filter thread is 40.5 mm for most members of the CX range except the wide 6.7-13 mm that uses 52 mm and the 10-100 that takes 55 mm filters. The 6.7-13 and 10-100 zoom lenses are quite short when they are in a parked position. You have to unlock it by pushing a release button on the lens casing and extend the lens to make it operational. This action also switches the camera on. When you lock the lens, the camera turns off. Quite practical unless you are in a hurry, but then the 1 Series isn't a concept for rapid action photography.

Through the adapters, a raft of other lenses are available. Thus I list only the ones most frequently employed on my 1 Series models.

  • Fisheye-Nikkor 16 mm f/2.8 AIS
  • 35 mm f/1.8 W-Nikkor (S mount)
  • Rodenstock Heligon 50 mm f/0.75
  • Nikkor 50 mm f/1.2 AIS
  • CRT-Nikkor 55 mm f/1.2 (goes to infinity focus on a short helicoid)
  • CV 125 mm f/2.5  APO-Lanthar (mainly video)
  • AFS 200 mm f/2 Nikkor (mainly video)

I'm going to post a number of pictures to demonstrate the visual diversity these cameras is capable of.


Let this picture taken by the humble kit lens (10-30 mm) be a starting point.

My little red car makes a splendid backdrop for this Red Clover specimen, and the reflections and shadows did the rest (1 V1)




This marvellous dandelion installed itself in front of my garage port some years ago, and has been with me ever since. Here I captured its basal rosette with the tiny 10 mm f/2.8 Nikkor (1 V1).



The f/2.8 aperture means you can do indoor shooting without too much troubles, here a classic study of Copenhagen Airport Kastrup,



The wide-angle zoom lens 6.7-13 mm provides a quite steep perspective as you can, and should, move in close to the subject. Here exemplified by a Hydrangea climbing a brick wall.



Another example is this magnificent Althaea rosea from Montenegro set against the Bay of Kotor (AW1),

The 18.5 mm f/1.8 is the 'normal' alternative in the lens line-up, and the speed allows its use under quite adverse light situations. It draws the background with a pleasing softness if used at wider apertures as demonstrated by this double portrait of two young girls (AW1);



The 18.5 also comes in handy for low-lit street scenes, such as this sudden dusting of snow on spring daffodils (AW1);



The 10-100 mm f/4-5.6 is a jack-of-all-trades item yet surprisingly powerful in optical terms. I got the lens not long ago so haven't shot it as extensively as the other CX lenses, but envision it to be very valuable for travel photography. Below is a shot of the Central Station of Oslo, the facade of which currently is emblazoned in bright colours (AW1);



The 10-100 exists in two different versions (built-in focusing motor or no motor) and is a nice partner for any 1 Series including the AW1. Recently Nikon added a 70-300 CX with VR. I found the latter difficult to use efficiently unless working from a tripod, but others might find it more attractive. The image quality of the 70-300 is very good, though, but its size dwarfs the 1 Series.








Bjørn Rørslett

  • Fierce Bear of the North
  • Administrator
  • ***
  • Posts: 8252
  • Oslo, Norway
Re: The World Is One
« Reply #1 on: June 18, 2015, 16:07:55 »
Next post will deal with AW Nikkors in CX mount. These lenses can only be attached to the AW1 due to their physical build.

Optically speaking these lenses are outstanding designs, and able to provide great image quality either below or above the water surface. What they cannot do, however, is act like domed lenses on modified (D)SLRs in underwater housings. Thus the boundary air-water will not be drawn as a thin line, instead there is a transitional effect in play. The image below, depicting flowering Water Crowfoot (Ranunculus aquatilis) shows this characteristic clearly;



Entirely submersed another world opens up for exploration. This very acid lake exhibits the typical bloom of diatoms and threadlike green  algae that combine to form a beautiful diffraction grid. The pads of the Yellow Water Lily break the ray bundles from the surface and make the colours come out even more vibrantly.



Both taken with the AW1 and the AW 1 Nikkor 10 mm f/2.8, which is my preferred underwater optic.


The AW 1 11-27.5 is great too, but its longer near distance means it is less suited for underwater close-ups. This is about as close as you can get (AW1, AW 11-27.5);


However, in optical terms the AW zoom lens outperforms the 10 mm and adds a lot of versatility as well. You do have the advantage, or pleasure, of being able to push the lens into dirt and mud pools to get unusual view points, such as this car capture;



There is no need to be shy of enjoying a bout of rain with such a camera/lens combination;



For underwater use, the AW 11-27.5 is more than long enough. If I could wish for a new underwater capable lens, that would be a wide-angle zoom akin to the terrestrial 6.7-13, or a dedicated fisheye with close-focusing ability. In particular anything similar to a close-focusing fisheye would be a tremendous benefit to the overall AW system.





Bjørn Rørslett

  • Fierce Bear of the North
  • Administrator
  • ***
  • Posts: 8252
  • Oslo, Norway
Re: The World Is One
« Reply #2 on: June 18, 2015, 17:46:18 »
Finally, one of the most exciting aspects of the1 Series range is the ability to use a wide variety of lenses through adapters. Nikon themselves provide the FT-1 which is beautifully made, is equipped with a tripod bushing, and is very expensive. Most "F" mount lenses can attach to the FT-1 and if they have CPU, all information is relayed to the camera. A quirk of the 1 Series is that manual focusing with magnification is only available for CPU-equipped lenses and these must be set in manual mode as well*. Don't ask me about the rationale for this behaviour because I haven't the slightest clue why Nikon opted for this 'solution'. Now, fortunately for me, virtually all my manual-focus Nikkors have been upgraded with a CPU and thus are fully compatible with the 1 Series. I get reliable metering and magnification of the scene when focusing.

* (added: may only apply to 1V1. Øivind Tøien advised me that there is a menu setting in the AW1 for the degree of magnification, in discrete steps 2,5,10X. Obvious he reads the manual :D . You cannot step through these like a properly configured 1V1, though. I tend to set the magnificatioin to 2X to avoid excessive amplification noise)

Compared to the m4/3 world, the number of third-party lens adapters for CX is much smaller, but you do get cheap and passable quality adapters on eBay and similar sites. Most offers are for "F" mount adapters, but you can get C-, Leica LTM, M42, and m43 adapters to CX as well. Strangely I was unable to locate any Nikon "S" > CX adapters, but what do you have friends for? Erik [Lund] aka Dr. Lens to the rescue again.

It is tempting to attach an 1 Series body to a really long lens to give 'reach', but practical considerations warn you that anything longer than 400 mm will be difficult to utilise properly. The reasons for this of course are the low weight of the camera and the very narrow angle of view manifested with the 1 Series, both combining to make demands on rock solid support not only critical, but also very expensive, and just finding the subject in the viewfinder/rear panel can be a challenge in itself.

The massive Rodenstock TV-Heligon 50 mm f/0.75 is of course a 'must' for the 1 Series. Due to the shorter register distance of the CX mount, the überfast 50 mm is pushed less outside its optical design domain and image quality therefore improves compared to its behaviour on say a Nikon F-mount camera. It will still be a far cry from getting to infinity focus, though.

Scentless Mayweed (1 V1, Rodenstock 50 mm f/0.75)



Another fast lens that thrives on the 1 Series is the CRT 55 mm f/1.2 Nikkor-O. This lens comes in a long Leica-thread barrel and is optimised for a narrow range of magnification, from approx. 1:4 to 1:5. Combined with a suitable focusing helicoid, it is possible to bring it to infinity focus on the 1 Series. Doing so will rapidly reveal that venturing beyond its designed range of magnification is rewarded by extreme curvature of field and lots of aberrations. Hardly surprising except for those believing that an extension ring won't impact lens quality because 'only air' is added.

Used at distances up to approx. 6 m (such as the street scene below), images are passably sharp across the entire CX frame, whilst more distant scenes end up only with the very centre recognisable. Flare due to spherical aberration is part of the fun when the CRT-Nikkor is abused in such manner.



One of my most frequently used Nikkors on the 1 Series bodies is the Fisheye-Nikkor 16 mm f/2.8 AIS. The 16 mm f/3.5 is sharper, but less easy to focus, and its near limit cannot compare with the f/2.8 model, which became able to focus even closer after a treatment by Erik [Lund] aka Dr. Lens.

The fisheye distortion is not very obvious within the CX frame and I rarely run any geometric correction later in the processing work flow. The 16 mm delivers sharp images with high contrast and I mostly use it for getting quite close views of the scene. Below are a few winter scenes taken with the 16 mm on a 1 V1.





The ubiquitous 50 mm f/1.2 Nikkor AIS is the perfect tool when you want to make dreamscapes. Here used on the Danish Store Bælt (Great Belt) bridge a hazy autumn day.



One of the images I like the most by the 1 Series is this, depicting autumn foliage on silver birches. Here a 14 mm f/2.8 Nikkor was pressed into service on my 1 V1.


Anthony

  • NG Supporter
  • **
  • Posts: 1601
Re: The World Is One
« Reply #3 on: June 18, 2015, 20:38:13 »
The 1 Series has added a couple of dimensions (at least) to photography.

The V1 has outstanding AF performance, making it an excellent action camera in low ISO situations.  It proved that mirrorless can shoot action.  It has produced at least two Pictures of the Week on NG/Fotozones.

The AW1 brings affordable under water photography to everyone.  It also has really quite good image quality.  It is probably the most versatile camera available today.

Each of these is highly portable.

What we need is for Nikon to treat it as a professional camera, with controls to match.
Anthony Macaulay

armando_m

  • NG Supporter
  • **
  • Posts: 3528
  • Guadalajara México
    • http://armando-m.smugmug.com/
Re: The World Is One
« Reply #4 on: June 18, 2015, 21:09:43 »
I have the V1 and it is a lot of fun

I really like that it can be very discrete, totally dark when using the viewfinder, save a little green led, and 100% silent, AF is fast and usually spot on

shooting in the street I'm usually hitting the ISO 400 barrier , or I get blurry shots , which sometimes turn out to be interesting, even when the Af is good and fast, the interface gets in the way so trying to shoot something quickly can be frustrating

here is a shot with the 85mm f1.8G , f1.8 1/10,000 ISO 100
Armando Morales
D800, Nikon 1 V1, Fuji X-T3

Jan Anne

  • Noob
  • Global Moderator
  • **
  • Posts: 2042
  • Holland
    • Me on Flickr
Re: The World Is One
« Reply #5 on: June 18, 2015, 22:36:08 »
After seeing Bjørn and Jakov play with the AW1 in the river and lakes an a few occasions I'm slowly getting excited to get one, especially when canoeing I'm close to water surface days at end with loads of nice opportunities to shoot half half or fully below the surface. Was thinking of getting a GoPro for that looks pretty restricted compared to what the AW1 can do.
Cheers,
Jan Anne

simato73

  • NG Supporter
  • **
  • Posts: 1128
  • You ARE NikonGear
Re: The World Is One
« Reply #6 on: June 20, 2015, 18:49:03 »
Bjørn, thanks for the opinion on the AW1.
Lika JA I have been thinking about it, since I am seldom satisfied by the performance of my RX100 in an underwater enclosure.
I will definitely get one if an opportunity at sufficiently reduced price presents itself.
Simone Tomasi

Erik Lund

  • Global Moderator
  • **
  • Posts: 6480
  • Copenhagen
    • ErikLund.com
Re: The World Is One
« Reply #7 on: June 28, 2015, 22:27:57 »
After seeing Bjørn and Jakov play with the AW1 in the river and lakes an a few occasions I'm slowly getting excited to get one,...
Indeed, those 'in the water line images' are superb!
Erik Lund

Øivind Tøien

  • NG Supporter
  • **
  • Posts: 1689
  • Fairbanks, Alaska
Re: The World Is One
« Reply #8 on: June 28, 2015, 23:31:28 »
Absolutely agree. Amazing to get that carp into the frame too.
For the record, I posted a review with more details on the AW1 and alternative wideangle optics here:
http://nikongear.net/revival/index.php?topic=356.0
Øivind Tøien

Erik Lund

  • Global Moderator
  • **
  • Posts: 6480
  • Copenhagen
    • ErikLund.com
Re: The World Is One
« Reply #9 on: June 29, 2015, 08:41:09 »
Indeed you did, there was so much information that I didn't get through the post the first times around... I will go back to it and digest more :)
Erik Lund

Øivind Tøien

  • NG Supporter
  • **
  • Posts: 1689
  • Fairbanks, Alaska
Re: The World Is One
« Reply #10 on: June 29, 2015, 11:41:26 »
 ;D ;D ;D
Øivind Tøien

KevinC

  • NG Member
  • *
  • Posts: 11
  • You ARE NikonGear
Re: The World Is One
« Reply #11 on: December 05, 2015, 15:51:59 »
Another vote in support of the 1 Nikon series.  I purchased a J1 refurbished with 10-30mm and 30-110mm lenses for $200, then picked up an S1 with 11-27mm and underwater housing for $200 again.  They are fine little cameras when one doesn't want the weight of a dSLR package.  On a recent safari trip, I brought a full dSLR kit, and both 1 Nikons, deciding that changing cameras would be safer than changing lenses in the dusty conditions.

Day one and two of the trip, my wife was asking why I brought four cameras.  By day three, she was referring to the 1 Nikons as "my cameras."  Between the two bodies and two lenses, she had a fast-focusing kit that covered 27-297mm full-frame-equivalent focal range with excellent daylight capabilities in a bag that could easily be hung on one's belt, with batteries, charger, and extra storage.

What I can't understand is Nikon's apparently complete incompetence in its marketing of the 1 Nikon series.  They have never put forth any good reason through advertisement why anyone should buy one.  New models come out every nine months.  They are cannabalizing their own sales.

But I just look for the "refurbished" models.  Great buys when 65% off list price.

Kevin


Ron Scubadiver

  • NG Member
  • *
  • Posts: 1245
  • Renegade Street Photographer
Re: The World Is One
« Reply #12 on: December 31, 2015, 04:24:22 »
Sharp images, very intense colors without looking over saturated.
